Deutsch DT Series Connectors

Rated at 13 amps continuous and accomodating wire sizes from 14 to 18 AWG, the DT Series connectors are the most widely used. The 2, 3, 4, and 6 contact connectors are available in Black or Gray and the 8 and 12 contact connectors are available in four different keyed and color coded configurations.



Deutsch DTM "Mini" Series Connectors

Rated at 7½ amps continuous and accomodating wire sizes from 16 to 24 AWG, the DTM Mini Series connectors are a compact alternative where space or weight is limited. The 2, 3, 4, and 6 contact connectors are available in Black or Gray and the 8 and 12 contact connectors are available in four different keyed and color coded configurations.



Deutsch DTMH "Mini" Series Connectors

High Temperature Rated, 7½ amps continuous and accomodating wire sizes from 16 to 24 AWG, the DTMH High Temp Mini Series connectors are a compact alternative where space or weight is limited. The 2 contact connectors are Black and are available in four different keyed configurations. DTMH connectors feature an integral wedgelock design.



Deutsch DTMN "Mini" Series Connectors

Non-Sealed , 7½ amps continuous and accomodating wire sizes from 16 to 24 AWG, the DTMN Non-Sealed Mini Series connectors are an economical compact alternative where an environmental seal is not required. The 2 and 3 contact connectors are Black and super easy to assemble and dis-assemble. DTMN connectors do not require a wedgelock.



Deutsch DTP Series Power Connectors

The DTP Series multi-contact power connectors are rated at 25 amps continuous and accommodate wire sizes from 10 to 14 AWG for high power applications. Available in 2 or 4 contact configurations in gray or black.



Deutsch DTHD Power Plug Series Connectors

Heavy duty is what the DTHD Series Power Plug connectors are all about. These single conductor connectors are available to accommodate wire sizes from 12 to 6 AWG for high current, heavy duty applications.



Deutsch Flange Mount Connectors

DT, DTM and DTP Series Flange Mount connectors are perfect for a professional bulkhead or firewall installation.



Deutsch Jiffy Splice

For fast, simple and economical single conductor splices in wire ranges from 18 to 6 AWG.



Deutsch DT Series Backshells

DT Series Backshells are Black Plastic and available in Straight (180°) or Right Angle (90°) configurations. Optional integral strain relief, for use with jacketed cable, is available. Backshells accomodate 6mm, 7.5mm, 8.5mm, 10mm, 13mm and 17mm corrugated tubing.



Deutsch Connector Boots

Deutsch Connector Boots feature Black or Gray, Plastisol in Straight Configurations. Available for DT, DTM and DTP Series Connectors.



Deutsch Connector Caps and Plugs

Available in various styles and materials for most series connectors.



Deutsch Connector Gaskets

Neoprene gaskets for non-gasketed Flange Mount Connectors



Deutsch Mounting Accessories

Use these mounting clips for a secure, reliable and professional installation.



Pins and Sockets

Genuine Deutsch Pins and Socket for all connectors.



Replacement Parts

Genuine Deutsch replacement parts to get the job done right.



Deutsch Connector Tools

The right tool for the job. Hand crimp tools and pin and socket extraction tools.



Batts Racing Deutsch Connector Kits

Our DT, DTM and DTHD/DTP Series Deutsch Connector Kits come with a selection of connectors and accessories for a complete and professional installation. Includes FREE storage box.



Batts Racing Deutsch Connector Wiring Harnesses

Our Wiring Harnesses are assembled with Solid Pins using genuine Deutsch 8-Indent Crimping Tool and Thin Wall Cross-link 125°C SAE J1128-GXL Automotive Wire.



Type GXL Automotive Wire

Building or repairing your own harness? We have your wire.



Gift Certificates

A great way to give Deutsch IPD Products.



Special Items

We have special and clearance items.
